Automatic CNC 3D Wire Bending Machine

 The 3D CNC wire bending machine builds complex-shaped 2D or 3D output forms. It is highly preferable concerning complex applications. Similar to the 2D wire bending machine, the 3D wire bending machine also works efficiently. Then, the user gets the precise output forms at any 3-dimensional complex shapes.

Auto Link manufactures 3 different models of 3D CNC Wire Bending Machines for different applications. These machines implement different bend processing according to the bending requirement. Hence, the wire bender receives wire directly from the coil, straightens, bends, and then cuts it accordingly. These actions accomplish by using built-in software to produce the right bend. This page depicts you with a short working principle of the CNC wire bending machine and applications.

Input materials: Stainless Steel, Aluminium, Brass, Bronze, Carbon Steel, Cold-Rolled Steel, Copper, Nickel, Titanium, etc.

CNC Wire Bending Machine – Working Principle:

The decoiler gives wire coiling as an input to the bending machine. [The machine cannot work effectively without a decoiler.] The capacity (loading weight) of the

decoiler is of 60Kg to 2000Kg. It then straightens using the straightener and the wire feeder with a roller. The user chooses the roller for the input wire diameter.

Then the wire guide achieves the bending formations with its 360° rotary. The wire guide provides multiple R angles. The bending tool comprises both inner and outer bendings which accomplish the difficult bends. Hence, the final part is cut using the cutting tool when the product bend over.

The servo motor and CNC programming unit ensure the machine’s working process. Auto Link builds CNC machines with custom language preferences. But then, the machines interfaced with both English and Chinese languages.

Processes involved in Bending Machining:

The automatic wire bending machine ensures threading, Chamfering, Bending, Cutting, End-forming, and punching processes. Steel wire bending machine performs effectively for producing various 2D/3D steel or metal bends. Therefore, the fully automatic wire bending machines increase the production rate.

3D CNC Wire Bending Machines – Applications:

This machine is applicable to both commercial and industrial purposes. Following are some of the applications… Auto Link is now expanding sales through Alibaba.

• Shoe Rack
• Grid Shelf
• Stainless Steel Chair
• Wall Fan Outer Cover

Available Models:WB-3D408R, WB-3D413R, WB-3D306R & WB-3D308R

Our wire bending machine is configured with two bending turrets. This is for ensuring the clockwise and anti-clockwise rotation. It then allows multiple bending technologies to perform on the same cycle. With the huge global network, Autolink Technology Co., Ltd supplies CNC wire bending machine globally. As a manufacturer, we give you a quality assurance and a service guarantee.
